Size Exclusion Chromatography Columns

With different pore sizes, Shim-pack Bio Diol LC columns are effective for analysis of aggregates and fragments of mAb, oligonucleotides and carbohydrates.


Shim-pack Bio Diol Diol-60 Diol-120 Diol-200 Diol-300
Particle Silica
Ligand Dihydroxypropyl(Diol)
Particle Size 3 μm,5 μm 2 μm,3 μm,5 μm
Pore Size 6 nm 12 nm 20 nm 30 nm
pH Range 5.0 - 7.5
Molecular
Weight Range
below 10,000 1,000 - 100,000 5,000 - 300,000 20,000 - 1,000,000


Features
