Standard sample introduction unit (for LCMS-2010)
Name P/N Appearance Qty Remarks Applicable models
Reflex fitting set
228-45407-92
Set of 5 Used for pipe connection from the 6-port valve to the ESI/APCI probe LCMS-2010
Microsyringe1005C
228-25237-07
228-25237-07 1 LCMS-2010
Rotary pump oil
Name P/N Qty Remarks Applicable models
Rotary pump oil  Ultragrade#19
017-30163-02
4L 1.5 L per use except 8080
except 8060
Sample delivery unit (for LCMS-8080)
Name P/N Qty Remarks Applicable models
PTFE tube
228-18495-01
1m Cut the tube into 20 to 30 mm length pieces before use. LCMS-8080
PEEK nut
228-18565-84
5 LCMS-8080
PEEK coupling
228-25014
1 LCMS-8080
Tee joint
225-25031-10
1 LCMS-8080
PEEK tube
228-33833-91
3m Inner diameter: 0.13 mm LCMS-8080
Straight joint
225-25031-07
1 LCMS-8080
Syringe for infusion analysis
225-25031-02
1mL Inner diameter: 4.61 mm LCMS-8080
